Anesthesia Workstation, with its ergonomic design, integrates a concise and smooth structure and high mobility. The microcomputer-controlled Ventilator adopts exported sensors and other components. Its scientific and proper design as well as rigorous production process are what demonstrate the inner quality. With multiple modern technologies applied, the Anesthesia Workstation is both outstanding in its performance and versatile in functions.

Mechanical ventilation is made secure and visible by the folded respiratory bellows and the security of air supply is guaranteed by pneumatic transmission and measurement system.

The Ventilator adopts microcomputer control with high-definition TFT color LCD display, integrating the functions of respiratory control and displaying the monitoring parameters. It is versatile in function and excellent in performance.

The high-precision Vaporizer is designed with a stable concentration output, automatic compensation for pressure, temperature and flow rate. And it is available to choose one kind of gas from Halothane, Enflurane, Isoflurane, and Sevoflurane, ensuring a successful anesthesia operation.

High-definition four-tube flowmeter, designed with stoppers for oxygen and nitrous oxide to control the output oxygen concentration.

Reliable pneumatic transmission system.

Part of Anesthesia Workstation

Main Body : High-strength engineering plastic rack, light, beautiful and corrosion resistant

Scope of Application : Adult and Child

Gas Source : O₂: 0.28~0.6MPa  N₂O: 0.28~0.6MPa

Flow Meter : O₂: 0.05~1.0L/min   1.1~10L/min

                   N₂O: 0.05~1.0L/min   1.1~10L/min

O₂, N₂O linkage and N₂O Stopper

When using nitrous oxide, oxygen concentration>25%;

When the oxygen pressure<0.2Kpa, the flow of nitrous oxide would be cut off.

Flow rate of rapid oxygen supply : 25~75L/min

Low oxygen pressure alarm : There will be sound alarm when the oxygen pressure < 0.2MPa

Vaporizer : It has the function of automatic compensation based on pressure, temperature, and flow rate. The regulation range of evaporator concentration is 0~5 vol%. Among Halothane, Enflurane, Isoflurane and Sevoflurane, one can be chosen for application as required by the customer.

Respiratory circuit working mode: all-close, semi-close, semi-open APL?12.5kpa

Respiratory Bellows :  Bellows for adults, bellows for children tidal volume range:0~1,500 ml

Part of Ventilator

Display mode : 10.4”TFT color LCD screen display

Ventilation  mode : IPPV, SIPPV, SIMV, MANUAL, VCV, PCV

Ventilation  function : PEEP,SIGH, IRV, IP, standby

Ventilation parameters : Tidal volume20~1600 ml

Rate 2~99 bpm

SIMV rate 2~20 bpm

I:E4:1~1:8

Inspiratory trigger pressure : -10~20cmH₂O

PEEP : 2~20cmH₂O

Pressure Range : 5~60cmH₂O
