Ventilator Vertical Deluxe is a multi-functional Ventilator, it is applicable for children and adults in sickroom, ICU or of emergency.

Ventilator

Display Mode : High-definition 10.4” TFT color LCD screen display

Ventilation Mode : VCV,PCV,SIMV,PSV,PSV+SIMV,CPAP

Ventilation Function : PEEP,SIGH, IRV, IP,Standby

Ventilation Parameters :

Tidal volume : 20~1800 ml

Rate                2~120bpm

SIMV Rate      2~120bpm

I:E                   4:1~1:8

Pressure trigger sensitivity  -10~10 cmH2O

Flow trigger sensitivity          1~20L/min

PEEP                                    0~25 cmH2O

Pressure Range                    3~50 cmH2O

Pressure limitation                5~60 cmH2O

Pressure slope                      1~10 gear

Flow rate setting                    1~10 gear

Time control                           1~10s

SIGH                                      1.5 times the inspiratory time (60-120 adjustable)

Inspiratory platform                0~50%

Oxygen concentration  21%~99%

Parameters for ventilation monitoring

Expired tidal volume, Inhale tidal volume, minute ventilation volume, IPPV rate, SIMV rate, total respiratory rate, autonomous inspiratory rate, I/E, peak pressure of airway, average pressure, PEEP, inspiratory trigger pressure, Inspiratory platform, oxygen concentration, battery capacity, pressure - time waveform, flow rate - time waveform, flow-volume loop, pressure-volume loop

Security Alarm System

Oxygen Concentration alarm : Upper limit setting range  21%~99%

                                                 Low limit setting range    18%~80%

Airway pressure alarm           : Upper limit setting range   5~60 cm H2O

                                                 Low limit setting range     0~50 cm H2O

Per-minute ventilation volume alarm : Upper limit setting range   1~20L/min

                                                            Low limit setting range   0~19L/min

Tidal volume : Upper limit setting range  10~1800ml

                       Low limit setting range   0~1700ml

Respiratory rate : Upper limit setting range  10~99bpm

                             Low limit setting range   0~50bpm

Sustained high-pressure alarm : It will give alarm when stress have consistently been higher than 30 cm H2O

Suffocation alarm : Intubation off alarm

Low pressure of Air alarm : Battery voltage alarm

Power : AC 220V  50Hz (UPS, Storage battery)
